  • Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
  • Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine

Fully Automatic Wood Cnc Router Machine

stars, based on ( 0 )reviews
$8500.00now$7479.26 unit
100items available

Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
Characteristic:
1) X,Y axises adopt gear-wheel, speed is fast. It adopts domestic no oil vaccum pump
with high efficiency.
2)Adopt Japan yaskawa servo motor ,built-in encoder,It can stop automatically when graunch happens,so can avoid accidents .
3)Whole machine is welded with seamless steel structure, the regidity is good , not easy to be deformed.The gantries adopt steel
structure
4)All adopt imported square oribit, heavy loading, stable working , high precision and long lifetime. Imported ballscrew , high
precision.
5).With 4 cylinder and 2 Pressure wheel for fix the material.
Performance parameter:
Description
parameter
XYZ working area
1300*2500*200mm
1500*3000*200mm
2000*3000*200mm
Table size
1440X3040mm
1640*3540mm
2140*3540mm
X,Y,Z Traveling Positioning Accuracy
±0.03/300mm
X,Y,Z Repositioning Positioning Accuracy
±0.01mm
Lathe Structure
Welded Strucutre
X, Y Structure
Gear Wheel Transmission, Shaft Linear Bearings
Z Structure
Ball Screw, Shaft Linear Bearings
Max.Consume Power
20KW
Max.Speed
0-60000mm/min
Max.Working Speed
0-25000mm/min
Spindle Power Motor
5.5 or 7.5Kw  spindle
Spindle Speed
0-24000RPM
Working Mode
Servo system
Working Voltage
AC380V/50/60Hz , 3PH
Command
G Code, *uoo, *mmg, *plt
Operating System
SYNTEC or Weihong System
Interface
Internet line
Flash Memory
512M
Collet
ER32
X,Y Working Delicacy
<0.01mm
Software
Type3 software, Wentai software,Artcam software
Running circumstance
Temperature: 0°C~45°C,
Relative humidity: 30%~75%
Packing Size
4000x2150x2200 mm
Net Weight
2000KG
Gross Weight
2300KG
Details Images
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine


Bed was milled by 5 axis CNC central machine,make sure the machine with high precision.




High quality guide Hiwin brand,make sure with high accuracy.
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine




Taiwan 2 die grinding rack,with high solidity and fast speed.





5.5 KW or 7.5 KW spindle can rotate 180 degree.
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine





With vacuum table ,can fix material tightly.




With positioning cylinder for locate the material sheet.
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine




Digital automatic lubrication system for lubricat guide easily.





Weihong or Syntec control system with disply.
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine




With two pressure wheel,can fix the material very tight when cutting.





Saw with diameter 400mm, cutting speed fast.
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine





With four cylinder for fix the sheet material .




With foot cushions，it can adjust the planeness easiliy.
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine




Hand-held pulse generator
Can control the switch ,easy to operate the machine.
Working Samples
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
Producing Process
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
Company Profile
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine Fully Automatic Wood Cnc Router Machine,wood cnc router,Large wood sawing machine
FAQ
Q1.How to get the most suitable machine and best price
Please tell the material you want to working on ?
How to working on it ? Engraving ? Cutting ? Or other ?
What’s the MAX size of these material ?( length ? Width ? Thickness ?)

Q2.What is the payment?
The payment is 30% or 50% T/T or Alibaba trade assurance in advance, balance after machine finished.

Q3.What is the producing time after order?
The proucing time is about 10-20 days depend on different machines.

Q4.If we don't know how to use the machine,can you teach us?
Yes,we will ,if you come to China,we will offer you free training until you can use machine freely.And if
you are busy ,we will have the special engineer to your country,but you need to bear some fee,like
tickets and hotel and meal.

Q5.How about your after-sales service?
we offer you 24 hours service phone,skype or whatsapp, our engineer also can go to door install or training.

Q6. Quality Control:
The whole production procedure will be under regular inspection and strict quality control. The complete machine will be tested to make sure they can work very well before being out of factory.
The testing video and pictures will be available before delivery.
